SERWA XPRESS Pre-Configured Goods Only Lift: Fast Delivery, Fast Installation In The UK
A pre-configured goods lift for warehouses, self-storage facilities and logistics operations, ready to install in as little as one week.
Planning a warehouse, logistics operation, or self-storage facility and need a goods lift that can be ordered, delivered, and installed without lengthy lead times or complex planning? The SERWA XPRESS is a pre-configured goods only lift with fixed cabin dimensions, ready to order from stock. No bespoke design process, no long wait. Delivered within 6 weeks and installed on site in as little as one week.
Pre-Configured, Fixed Dimensions, Ready to Order
The SERWA XPRESS is a pre-configured goods only lift with a fixed cabin size of 1,200 x 1,700 x 2,000 mm and a lifting height of up to 6 metres. It handles loads of up to 1,000 kg at a nominal speed of 0.2 m/s whether loaded or empty. The enclosed shaft provides a high level of safety and requires a pit of just 60 mm, with a ramp option available where pit excavation is not practical. Suitable for 2 or 3 stops with stacked or opposite access configurations.
The SERWA XPRESS is used across warehouses, logistics buildings, self-storage centres, workshops, and production halls throughout the UK. It supports fast, safe vertical goods transport between floors, reduces the need for manual handling of heavy loads, and helps improve throughput in busy storage and distribution environments. Because it requires no wall fixations and is ground-floor mounted only, it fits into both new-build and existing facilities with minimal structural impact.
Benefits
Comprehensive Service for Your Goods Lift
Reliable support: before, during and after installation
At Lödige Industries, we supply your goods lift and support it throughout its entire working life. From initial planning through to regular maintenance and modernisation, our experienced UK team is here to assist you at every stage.
Our experts assist you with lift positioning, shaft requirements, and site preparation — ensuring a smooth and fast installation process.
We make sure your lift is perfectly configured and tested on site. Safety and performance are fully validated before handover.
Want to add features later or adapt to changing operational requirements? We offer tailored modernisation services years after the original installation.
Regular service ensures reliability and compliance. We offer maintenance packages tailored to your operating hours and usage levels.
For advanced lift systems, we provide fault analysis and recommendations — even remotely.
SERWA XPRESS Technical Specifications
| Load Capacity | 1,000 kg |
| Lifting Height | max. 6 m |
| Nominal Speed | 0.2 m/s |
| Cabin Width | 1,200 mm |
| Cabin Depth | 1,700 mm |
| Cabin Height | 2,000 mm |
| Pit Depth* | 60 mm (or ramp) |
| Stops | 2 - 3 |
| Access Points | 2 - 3 (stacked or opposite) |
| Passengers | Not allowed. Goods transport only |
| Sill Load | 60% of rated load. Forklift use prohibited |
| Shaft Width | 1,570 mm |
| Shaft Depth | 1,880 mm |
| Shaft Head Height* | min. cabin height + 450 mm |
| Installation Width/Depth | Shaft width/depth + 40 mm all around |
| Control System | Call and send control |
| Drive System | Electric with chain, 5 kW, S3/S6 - 75% |
| Control Cabinet Position | Directly beside the shaft |
| Operating Mode | Manual loading by hand without an accompanying person |
| Directives | Machine Directive 2006/42/EC DIN EN 81-31 (on the basis) |
